Win3 X4 Intelligent gas instrument multi-gas detecion

The coal industry takes safety issue the first priority. The mining explosion is the biggest risk in underground mining. Methane released from the coal seam and surrounding rock strata during the process of mining operation can present a high risk of explosion at concentrations in air of 5-15%

Win3 Intelligent Gas Detector is specially designed for underground mining, it  meets the requirements for miners safety and developed mainly for the detection of methane, hydrogen sulphide, carbon monoxide and oxygen levels (along with 50 other possible gases)

Win3 Gas Measuring Instrument adopts the latest sensing system (infrared+electrochemical+catalytic combusion), it is suitable for the detection of many kinds of toxic and explosive gases, real time down loading of exception events to control room and alert to cap lamps or the mated system

4GB SD card, remote outstation logging and data output, real-time down loading of exception events to control room.

With latest technology,dust/water proof material, portable gas measuring instrument is fited with a ultra wide band(UWB) data radio that can be used for multiple wireless applications. Warranty - 12 Months (T&Cs)
  • det02
GAS INSTRUMENTSSS Specification
Approval certificates: SANS/IEC 60079 Part 0: 2012, Pait 11:2012,Part 29-1,SANS 1515-1:2014,FCC
Number of Gases: Up to 5 Gases Simultaneously
Detectable gas: CH4/CL2/Co/CO2/H2/H2S/HCL/HCN/Hydrocarbons/NH3/NO/NO2/O2ISo2voc
Measuring range: % LEL, % Vol, ppm - Sensor dependant
RF Range: Up to200m - Radio link can communicate with Vehicle | Machine / Cap-lamp
Accuracy: +/-0.1% or +/-6ppm - Sensor dependant
Electric current: 190mA with back light, 260mA with back light and radio - Sensor dependant
Battery: 3.7VDC, 2800mAh - Li-Po
Operating temperature range: -10 to +40℃
Operating humidity range: Maximum 95% non-condensing
Display : Graphic colbur display - lcon based menu, animated video, real time gas graph
Alarm broadcast: Alarm broadcast to cap lamps in same vicinity as instrument
Audio alarm: Greater than 85db
Visual Alarm: Colour coded, omni-directional
Vibrating alarm: Optional
Response time: T90 in less than 15 seconds for flammable and less than 35 seconds for toxic
Battery life: Up to 24 hours - Sensor dependant
Size: 126mm x78mm x43mm
Weight: 320g
